Rice Lake 189159, 10K lb Cap, Alloy Steel Environmentally Sealed Load Cell, NTEP
|Full Scale Output||3.0mV/V|
|Resistance||(Output) 350 (±3) ohm (Input) 400 (±20) ohm|
|Seal Type||Environmentally Sealed, IP76|
|Cable Length||20 ft|
|Safe Overload/Sideload||(Overload) 150% full scale (Sideload) 100% full scale|
Product DescriptionThe load cell is interchangeable with Rice Lake RL35023, VPG Sensortronics 65023A, and VPG Celtron SQB load cells. Cable color code is as follows; red is positive excitation, black is negative excitation, green is positive signal, and white is negative signal. Each load cell has 20 feet of cable and is FM approved and NTEP approved Class III, 1:5,000 from 1,000 lb to 10,000 lb. Output Resistance: 350 (± 3) ohm. Output Resistance: 350 (± 3) ohm. Temperature: Compensated range: -14° F to 104° F/-10° C to 40° C, Operating range: 0° F to 150° F/-18° C to 65° C. Rated Excitation: 10 VDC (15 V maximum). Combined Error: 0.017% full scale.
One of our agent will get back to you as soon as possible
Price : $353.00
Because our price on this item is lower than the manufacturer's suggested retail price, the manufacturer does not allow us to show you our price until you place the item in your shopping cart. Retailers like Amazon have the legal right to set their own prices independently. Adding the item to your cart allows Amazon to show you our price consistent with our goal of always offering you the lowest possible prices on the widest selection of products.
Adding this item won't require you to purchase the product. You can easily remove it from your cart if you decide not to buy it.
